Multi-Mode Radar Simulation
  • Ground Mapping
  • Syntheric Aperture
  • Multiple Range Scales and Expansion
Antenna Model
  • Stabilization
  • Scan Rates and Slewing
  • Selectable Scan Widths
  • Gimbal Limits
  • Vertical and Horizontal Patterns
Spatial Effects
  • Range and Atmospheric Attenuation
  • Earth Curvature and Refraction
  • Shadows
  • Incidence
  • Target Aspect
  • Seasonal Effects
  • Sea State
  • Far Shore and Leading Edge Brightening
  • Noise Texture
Receiver Model
  • STC
  • Transfer Characteristics
  • Noise and Gain
  • Log Compression
Doppler Effects
  • Range/Doppler Response
  • Speckle
  • Range Foreshortening and Layover
  • Blind Zone
  • Batch and Line-by-Line
Display Features
  • PPI and Expanded Formats
  • Ground Track and Cursor Referenced
  • Drift and Velocity Stabilization
  • Symbology
Database Source
  • Industry Standard OpenFlight visual database, augmented with USGS cultural data
System Design Features
  • Low and High Fidelity Applications
  • Low Cost Platform
  • Compatible with Popular Operating Systems (eg. Windows 2000, Linux)
  • Scalable and Configurable Design is cost effective for adaptation to specific performance/functional requirements
  • On-line parameter changes for tuning image quality and radar characteristics
  • Correlation with Other Simulation Subsystems
-
  • Additional Radar Modes
  • Multi-Channel Output
  • Fixed and Moving Models
  • Weather/Thunderstorms
  • ECM/ECCM
  • Malfunction Simulation
  • Mission Functions
    (eg. Terrain Height, Intervisibility)
  • Correlation with Various Earth Models
  • Import of Additional Database Sources
    (eg. SEDRIS, SIF, proprietary formats)
